Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
Mast Motorsports Camshaft LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2
$ 420.00

LS "IKNA-1" Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2

+

Only left in stock

LS Camshaft 0.662/0.662 Lift 224/236 Duration- Lobe Sep 112+2

Technical Specs

  • Nickname: IKNA-1
  • Engine Type: LS
  • Induction Type: Naturally Aspirated
  • Sound Type: Mild Choppy Idle
  • Recommended Cubic Inch:  6.0/6.2
  • Application: Street Car
  • Intake Lobe Duration @ 0.050: 224
  • Exhaust Lobe Duration @ 0.050: 236
  • Lobe Separation: 112+2
  • Direct Injection Fuel Lobe: N/A
  • Timing Gear Type: Three Bolt
  • Intake Lobe Lift: 0.368"
  • Exhaust Lobe Lift: 0.368"
  • Intake Valve Lift w/ 1.7 rocker: 0.626"
  • Exhaust Valve Lift w/ 1.7 rocker: 0.626"
  • Intake Valve Lift w/ 1.8 rocker: 0.662"
  • Exhaust Valve Lift w/1.8 rocker: 0.662"
  • Rocker Arm Recommendation:  Factory w/ Trunnion Upgrade
  • Valve Spring Recommendations: Mast Dual Spring Kit
