800 HP - 466 cubic inch tall deck LSR - Black Label Race Dry Sump Engine
Type: LSR Tall Deck
Displacement: 466 Cubic Inches
Compression Ratio: 11.5:1 (100+ Octane)
Bore x Stroke: 4.160 x 4.250
Rev Limit: 8500 RPM
Crank: Callies Magnum
Rods: Callies Ultra H-Beam
Pistons: Wiseco Custom 2618 Alloy
Cam: Mast 3-Bolt Core Cam
Heads: Mast Black Label LS7 305 Heads
Intake: Holley Hi-Ram EFI
Valve Springs: PSI
Does not come with wiring harness or ECM
*All hp numbers will be within 2% of the advertised number.
Concept Performance LSR Tall Deck, Raised Cam, Double Crossbolt BlockCallies Magnum
4.250" Stroke 2.100" Journal
Callies 6.460 Ultra H Beam 2.100
Wiseco 4.155 Bore (466 Piston)
Main Bearings - Clevite
2.100" Rod Bearing
2.100" Rod Bearing -1
Custom Cam from Cam Motion
ARP 3-Bolt Cam Fasteners
Crower LSX Solid Roller Lifters
Rollmaster Dual Roller w/Torrington Bearing Timing Set
LS2 Timing Chain Guide
Gen IV Cylinder Head Dowel
LS7 305cc 12 Degree Large Bore (70cc)
2.250' 5/16 Titanium Race Valve 5.550' Long
1.600' 5/16 Titanium Race Valve 5.550' Long
PSI Valve Springs
Xceldyne 8 Degree 5/16" +.050 Shoulder Valve Lock
Xceldyne X2 Steel I.D. Spring Locater for 1571 Spring
GM Gen IV Valve Seals
Jesel Rocker System for Large Bore Heads 8mm Stand Bolts 'Inline Pattern'
Smith Brothers Custom Pushrods
GM LSX 4.185' Bore .040' MLS Head Gasket - Right
GM LSX4.185' Bore .040' MLS Head Gasket - Left
Arp 6 Bolt Head Stud Kit
LS1/LS2/LS3/LS6 Timing Cover (Fits RHS® or GM Blocks)
Cam Sensor
Gen IV Crank Sensor
Gen IV Oil Pressure Sensor
Gen IV ECT Sensor Plug
Gen IV ECT Sensor
Bosch MAP Sensor
Knock Sensors
Valley Cover
Mast Cast LS Race Valve Covers with Side Mount Kit
Coil Packs
Mast LS Gen IV Plug Wire Set
Racing Spark Plug -7
LS7 Hi-Ram EFI Intake Kit (105mm Throttle)
Holley Fuel Rail Kit for Hi-Ram Intakes
RHS Tall Deck LS Alum. Race Block Intake Spacer Kit (LS7)
Holley 105mm Throttle with Tapered Bore
Fast EV1 89.7 LB Injectors
Coolant Crossover Tube
Gen IV Coolant Passage Plug
Gen IV (Non LS7) Oil Pan Gasket
LS Crank Bolt
Dailey Dry Sump
ATI Y-Body 10% UD Dampner with HTD Pulley
Meziere LS1 electric water pump, black
